GPon EPon Dual Model XPon ONU Wifi 6 Wireless Router

GPon EPon Dual Model XPon ONU 4GE 2.4G 5G Dual Band Wifi 6 AX3000 Wireless Router

Overview：

The wifi router onu X1430 is a XPON (GPON and EPON dual mode adaptive) optical terminal access device that is highly integrated with dual-frequency Wi-Fi6 AX3000. It is the end-product of optical fiber for operators. It supports ultra-bandwidth access through G/EPON upstream technology and provides users with basic WIFI functions, routing, and gigabit Ethernet functions. The upstream network ports of the X1430 are G/EPON ports. The downstream user ports include 4 GE RJ45 ports, one USB port,one VOIP port and AX3000 WiFi6 WLAN ports. Compatible with mainstream GPON/EPON OLT, such as Huawei, ZTE, Fiberhome, etc.

Interface：

1 * G/EPON interface: SC/UPC/APC interface, ITU-T G.984,IEEE802.3ah
4 * Ethernet interface: 10 MBPS / 100 MBPS, 1000 MBPS, RJ - 45, IEEE802.3-2005 standard
1 * VOIP interface: in accordance with G. 711 a/u, G. 729 a/b, G. 722 standard
1 * USB interface: standard USB 3.0 interface
Dual-band WIFI6 AX3000 (2 ×2 MIMO (2.4G&5G))

wifi router onu

Hardware Parameters
Flash	256MB NAND
Memory	512MB DDR3
LED	POWER+PON/LOS+NET+LAN+POTS+WiFi+WPS+USB
Port	4*RJ45(GE)
	1*RJ11(POTS)
	1Reset+1Power +1LED button+1WiFi button+1*WPS
	1*SC/UPC (or SC/APC)
	1*POTS
	1*DC
	1*USB3.0
Size	19013533mm
Consumption	≤8W
Interface Parameters
G/EPON Port	GPON:Class B +
	EPON:PX20+
	GPON:Upstream1.25Gbps;Downstream:2.48Gbps
	EPON:Upstream1.25Gbps;Downstream:1.25Gbps
Ethernet Port	Ethernet port-based VLAN tags and tag removal
	VLAN transparent and mark
	MAC address learning
	MAC address learning limit
	100/1000/1000Mbps Autonegotiation
VoIP Port	G711A/G711U/G729/G722
	SDP protocol (RFC 2327 and RFC 4566)
	T.30/T.38/G.711 fax mode
	DTMF
USB	USB3.0
WiFi6（AX3000）
WiFi protocol	2.4GHz supports
	802.11b/g/n/ax
	5GHz supports 802.11a/n/ac/ax
Transmit power	2.4G 100mW,5G /200mW,
Antenna gain	5dBi
Antenna	dual-antenna MIMO (2*2) (2.4G&5G)
WLAN penetrate	one reinforced concrete wall or two ordinary brick walls (non-reinforced concrete),
WLAN access capability	64 /SSID
channel	2.4GHz（channel 1-13）
channel	5GHZ（channel 36-161 ）
WPS	WLAN terminal devices with WPS Push Button function establish connection within 2 minutes
WLAN security function	WPA-PSK、WPA2-PSK、 WPA3、WPA-PSK/WPA2-PSK AES、AES+TKIP
Air Speed	574 Mbps (2.4GHz)，2402 Mbps (5GHz)
Multicast	WMM(Wi-Fi Multi Media)
Environment
Operating Temperature	0℃~45℃
Storage Temperature	-20℃~70℃
Operating Humidity	5%～95%（non-condensing）
Power Supply	12V/1.5A
